Light Steel Structure Luxury Modern Villa Prefab House Kits Hurricane Proof

Modern Light Steel Villa Steel Structure Prefab House Kits Hurricane-Proof Luxury Villa

Delft House

 5 bedrooms 3 bathroom 1 Living  2 Garage 345.94 m²

Introducing the Delft House - Where Dutch Design Meets Smart Prefab Living (307.48㎡)

Meet our DPBL-25-37 model - the Delft House, a brilliantly engineered 307.48㎡ two-story residence blending contemporary functionality with timeless aesthetics. Designed for modern families who value both space and efficiency, this home delivers 4 bedrooms, 2 living areas, 1 chef's kitchen, 2 bathrooms, and double garages - all wrapped in DEEPBLUE's signature smart construction.

Floorplan:

Total Area: 307.48㎡
Dimensions: 13.5m × 22.7m (Generous proportions for elegant living)
4 Bedrooms (Including master suite with walk-in potential)
2 Living Areas (Formal lounge + casual family space)
1 Oversized Kitchen (Designed for serious cooking & entertaining)
2 Full Bathrooms (Premium fittings included)
2 Garages (Because one is never enough)

• Product parameters:



  Name:	Delft House
  Size:	13539×22658mm
  Ground floor area:	214.86qm
  First Floor Area:	92.62sqm
  Total Area:	307.48sqm
  Model:	DPBL-25-37







Applications:

Hotel, House, Office, etc.

Specifications:

ISO standard steel structure house .one or two also three floors available. fireproof, heat insulation, wind, and earthquake resistance. green, energy-saving. economically.

Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance: all the materials used can be fire-resistant.
5)Snow resistance: max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11)Installation: the average is one worker one day install one SQM.
12)Installation guide: dispatch engineer to guide on site.

Design code:

(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.

Resistant to various weather conditions, due to its light gauge steel framing system, DeepBlue Mobile Homes can resist winds up to 50m/s, 50cm snow loads as well withstand earthquakes due to its special steel structure technology.

The DeepBlue Mobile Houses manufacturing technology is truly a mature product characterized by flexibility and innovative design and solution.

Based on our patented foldable technology, transportation and erection can be done in a very simple and convenient way in order to save lots of time, energy, and unnecessary expenses.

Your first choice, Deepblue Prefabrica
